VCMU
Heavy Duty Universal Projector Mount
SKU
23290
MPN:
VCMU
- Independe nt roll pitch and yaw adjustments for quick and precise projector registration
- Multiple installation options: flush mount to ceiling use 0.5" threaded rods use a 1.5" NPT extension column
- Quick connect/disconnect for convenient lamp and filter access on most projectors
Overview
This mount provides the strong support you need for mounting heavy projectors. Micro adjustments allow you to quickly achieve registration. The VCMU mount includes the universal HBU bracket that is compatible with most heavy duty projectors.
Features
- Independe nt roll pitch and yaw adjustments for quick and precise projector registration
- Multiple installation options: flush mount to ceiling use 0.5" threaded rods use a 1.5" NPT extension column
- Quick connect/disconnect for convenient lamp and filter access on most projectors
- Cable management through top of the mount without additional accessories
- Easy 3-Step Installation
- 1) Assemble legs to projector
- 2) Fasten legs to universal bracket
- 3) Hook bracket onto VCM mount
- Heavy Duty Steel Construction
- Weight Capacity: 250lbs
- Universal bracket also sold separately (HBU)
Specifications
| Color | Black |
| Solution Type | Universal |
| Roll | ?5° |
| Pitch | ?20° |
| Yaw | 360° |
| Weight Capacity | 250 lb (113.4 kg) |
| Dimensions | 3.8" x 14.6" x 12.3" (97 x 371 x 312 mm) |
| Packaging Info | |
| Package Weight | 43.2 lb |
| Box Dimensions (LxWxH) | 25.0 x 16.5 x 11.5" |
Support
Manuals & Technical Documents
Technical DrawingsChief-VCMU-Technical Drawing
