Chief ODMLT Tilting Outdoor Wall Mount
ODMLT
Tilting Outdoor Wall Mount
SKU
70259
MPN:
ODMLT
- Weather proof design with outdoor-rated finishing & stainless-steel hardware
- 175 lbs (79.4 kg) weight capacity
- Universal interface fits most indoor and outdoor displays with up to 640x430mm VESA patterns
Overview
Designed to support all-weather outdoor installations and enhance the viewing experience. The ODMLT Tilting Outdoor Wall Mount provides fingertip tilt for optimal viewing, and features a weatherproof design including protective outdoor-rated finishing and stainless-steel hardware.
Pair with most indoor or outdoor displays for outdoor digital signage, outdoor living and humid indoor environments.
Features
- Weather proof design with outdoor-rated finishing & stainless-steel hardware
- 175 lbs (79.4 kg) weight capacity
- Universal interface fits most indoor and outdoor displays with up to 640x430mm VESA patterns
- Centris technology provides +5/-15 degrees of effortless fingertip tilt
- GlideLock with kickstand to secure the display to the wall plate without tools and for easy cable connection
- Padlock feature for additional security (padlock not included)
Specifications
| General: | |
| Color | Black |
| Lateral Shift | 2" (51 mm) |
| Minimum Depth | 3.27" (83 mm) |
| Mounting Pattern Compatibility (Universal Versions) | 127 x 100 mm - 643 x 430 mm |
| Orientation | Landscape |
| Overall Dimensions (H x W x D) | 18 x 29 x 3.27" (457 x 737 x 83 mm) |
| Solution Type | Universal |
| Tilt | +/-15? |
| Typical Screen Sizes | 32-80" |
| Wall Stud Compatibility (inches) | 16", 24" |
| Weight Capacity | 175 lbs (79.3 kg) |
Support
Manuals & Technical Documents
Technical DrawingsChief-ODMLT-Technical Drawing
