Analog Input 4-Channel, 1200W Amplifier
Click image to open expanded view


The CDi DriveCore Series is an evolution in amplification, providing an impressive mix of high-performance; rich feature set, and competitive cost.  Using technology derived from our flagship Installed Sound amplifier (Crown DriveCore Install series), the CDi DriveCore 4|1200 offers streamlined functionality to work in almost any large sized installation such as cinema, houses of worship, hotels, cruise lines, and more.

Designed for ease-of-use in a variety of applications, the 4|1200 is a 4-channel amp that includes network control/monitoring, high-level DSP, front-panel interface, and support for driving up to 100Vrms speaker loads without requiring a transformer. The entire CDi DriveCore line comes pre-loaded with JBL speaker tunings to help make installations quicker and easier.


  • DriveCore™ Technology: Crown’s proprietary DriveCore technology eliminates hundreds of components within each amplifier, reducing the variability of component values, increasing reliability, resulting in incredible audio fidelity from an efficient design.
  • Network Control and Monitoring: Through HARMAN’s HiQnet Audio Architect software, the CDi DriveCore can be controlled, configured, and monitored through standard TCP/IQ network.
  • DSP: On-board Digital Signal Processor in each amplifier allows for custom configuration and includes these integrated features:
    • Input Router
    • Input Delay – Up to 1000ms
    • Input Parametric EQ – 8 band
    • Crossover
    • Output Parametric EQ – 8 band
    • Output Delay – Up to 100ms
    • LevelMAX™ Limiter
  • Direct Drive 70/100Vrms Output: Each output channel is capable of providing either 70V or 100V for high impedance applications.
  • Front-Panel Interface: Completely configure the amplifier using an intuitive front-panel interface.
  • GPIO/AUX Port: Recall presets, mute channels, monitor faults, power on/off the amplifier, and more through a combined GPIO/AUX Port.
  • Pre-loaded Speaker Tunings: For quicker and easier setup and installation.


 BLU link No
Channels 4
Sensitivity (for full rated power at 8 ohms) 0.7V RMS
Rated Power Output (per channel @ 4 ohms) 1200W
Analog Input Signal to Noise Ratio (ref. rated power, 100V, 20Hz - 20kHz) at 8 ohms) > 104dB
THD (full rated power, 20 Hz - 20 kHz) 0.35%
Damping Factor (20 Hz to 100 Hz) > 1000
Frequency Response (8Ω, 20 Hz - 20 kHz) +/-0.25dB
Crosstalk (below rated power) 20 Hz to 1 kHz > 80dB
Input Impedance (nominally balanced, nominally unbalanced) 20 kΩ balanced, 10 kΩ unbalanced
Dimensions (inches) (W x H x D) (depth not including 1.3 inch front panel protrusion) 19 x 3.5 x 14.71
Weight 20.1 lbs (9.12 kg)
Power Supply Connector "20A IEC connector, 100 – 240V"



Manuals & Technical Documents

ManualsCrown Audio-CDI4X300BL-Manual.pdf
SpecificationCrown Audio-CDI4X1200-Spec Sheet.pdf
